Sliding & Cantilever Gate Collection
These project images help explain the lateral travel, support steel, guide hardware, clearances, and site space required for sliding gate systems.
Showing 12 of 31 project photos
What the photos show
Visible scope and planning boundaries
Visible in this collection
- Sliding gate frames and infill
- Guide posts, rollers, tracks, and cantilever support
- Opening clearances and operator-ready layouts
Plan before fabrication
- A sliding gate needs enough protected lateral storage beyond the clear opening.
- Grade, drainage, snow or debris, vehicle movement, and support foundations influence the layout.
- Automation and safety accessories should be planned around the complete moving-gate geometry.
Have a similar metal project?
Send photos, rough measurements, the property type, intended use, and your target timing. We will help define the fabrication and installation scope.
